MX100‑24LF 25.6V 100Ah LiFePO₄ Deep‑Cycle Battery -Maxela
MX100-24LF
ENHANCED LITHIUM BATTERY
25.6V100Ah LiFePO4 Battery
Maxtela HLB Lithium Battery, deep cycle,
long life cycle rechargeable battery
High‑capacity 25.6V 100Ah LiFePO₄ battery with advanced BMS for deep‑cycle use in industrial, solar, telecom, and mobile power systems. Lightweight, long‑life & lead‑acid replacement.
25.6V 100Ah Industrial LiFePO₄ Lithium Battery | High-Efficiency Lead-Acid Replacement | Maxtela
The Maxtela MX100-24LF is a premium 25.6V 100Ah LiFePO₄ deep-cycle battery, delivering high energy density and long cycle life. It is designed for solar energy storage, industrial systems, telecom base stations, and electric vehicles, offering a lightweight, maintenance-free, and environmentally friendly solution to replace lead-acid batteries.
Features：
-
High energy density – 40% lighter than lead-acid batteries
-
Long cycle life – Over 3000 cycles at 80% DOD
-
Built-in smart BMS for complete protection (overcharge, overdischarge, short-circuit, etc.)
-
Fast charging capability, low self-discharge
-
Maintenance-free & eco-friendly – ideal for harsh environments
-
Modular design – support parallel/series expansion
Specification：
| Parameter | Value |
|---|---|
| Nominal Voltage | 25.6V |
| Rated Capacity | 100Ah (2560Wh) |
| Charge Voltage | 29.2V |
| Discharge Cut-off Voltage | 21.6V |
| Max Discharge Current | 100A |
| Dimensions (L×W×H) | 522 × 240 × 218 mm |
| Weight | 26.4 kg |
| Charge Temp | 0 ~ 55°C |
| Discharge Temp | -20 ~ 60°C |
| Storage Temp | -10 ~ 45°C |
| Communication (optional) | RS485 / CAN |
Applications
-
Solar energy storage systems (off-grid & hybrid)
-
UPS backup & telecom base stations
-
AGVs, industrial automation equipment
-
Electric vehicles, golf carts, marine & RV power
-
Mobile CCTV and surveillance systems
Trust Maxtela for dependable and high-performance energy storage solutions.
