MX054-24LF 25.6V 54Ah Rechargeable LiFePO₄ Battery-Maxtela
MX054-24LF
ENHANCED LITHIUM BATTERY
24V54Ah LiFePO4 Battery
Maxtela HLB Lithium Battery, deep cycle,
long life cycle rechargeable battery
Maxtela's Enhanced Lithium Iron Phosphate (LiFePO4) Battery Series with high power energy and a long life cycle, a specific design to fit its wide range capabilities relying on the built-in BMS. Enhanced Lithium Battery Series offers excellent performance and leverages with intelligent technology, to last the protection throughout the whole use. Suitable for use in AGV, Storage energy, Telecom, Mobile motors applications, and much more. (Customized design is also available when you need it.)
25.6V 54Ah Deep Cycle LiFePO₄ Battery for Solar & Backup Power
Maxtela's 25.6V 54Ah LiFePO₄ battery is a high-performance, deep-cycle lithium solution designed for demanding energy storage applications. Built with reliable lithium iron phosphate (LFP) cells, it offers superior safety, over 4000 cycles of lifespan, and a compact footprint ideal for solar systems, UPS backup, industrial automation, and more.
This battery is equipped with an intelligent Battery Management System (BMS) that ensures safe operation under all conditions—overcharge, over-discharge, short-circuit, and temperature variations.
Features：
-
Long Cycle Life: Over 4000 cycles at 80% depth of discharge (DoD)
-
Stable Chemistry: Safe and thermally stable LiFePO₄ technology
-
Integrated BMS: Protection against over-voltage, under-voltage, over-current, short-circuit, and over-temperature
-
Maintenance-Free: No acid, no water filling, no memory effect
-
Compact & Lightweight: Easy to install in space-limited environments
-
Fast Charging: Supports high-rate charging with stable output
-
Eco-Friendly: Non-toxic and recyclable materials
Specification：
| Parameter | Specification |
|---|---|
| Nominal Voltage | 25.8 V |
| Rated Capacity | 54 Ah (1382.4 Wh) |
| Cell Type | LiFePO₄ |
| Cell Voltage | 3.2 V |
| Charge Voltage | ≤ 25.8 V |
| Cut‑off Voltage | ≥ 21.6 V |
| Max Discharge | ≤150A |
| Self‑Discharge | ≤ 3 %／月 |
| Charge Temp | 0～45 °C (32～113 °F) |
| Discharge Temp | –20～60 °C (–4～140 °F) |
| Storage Temp | –10～40 °C (14～104 °F) |
| Dimensions (L×W×H) | 330 × 173 × 216 mm (12.95″×6.77″×8.8″) |
| Weight | 13.5 kg (29.76 lbs) |
| Terminal | T11 (8 mm STUD) |
| BCI Group | 31 |
| Communication(Option) | RS485／CAN |
Applications
-
Solar Energy Storage Systems
-
Off-grid and Backup Power for Homes and Offices
-
Telecommunication Base Stations
-
UPS (Uninterruptible Power Supply) Systems
-
Industrial Equipment and Automation
-
Marine & RV Power Solutions
